Stop Guessing Where the Leak Is — Call Masters Plumbing Service in Carr, CO
A water bill that jumped 30% with no change in usage. A ceiling stain that keeps reappearing after patches. A soft spot in the flooring with no visible source. These are signs of a hidden leak that's been running long enough to cause structural damage — and every day it runs is money lost and damage accumulating. Masters Plumbing Service uses acoustic ground microphones, thermal imaging cameras, and precision pressure testing in Carr, CO to locate leaks without speculative demolition.
The Tools Behind Accurate Leak Detection in Carr, CO
No single detection method works for every leak scenario. Our technicians are trained on four distinct approaches and select the right tool — or combination of tools — based on the pipe type, building construction, and leak characteristics.
🎙️
Acoustic Ground Microphone
Acoustic detection is most effective on metal pipe (copper, cast iron) under slab or in concrete — materials that conduct sound efficiently. It works in quiet environments and requires shutting off the house briefly to establish a clean acoustic baseline.
🌡️
Infrared Thermal Camera
Thermal imaging is particularly effective inside insulated wall cavities and for finding the extent of moisture spread beyond the immediate leak point. It tells us not just where the pipe is failing but how far the moisture has already traveled.
📉
Pressure Decay Testing
Pressure decay testing is the standard by which we confirm a leak is present before committing detection equipment time. It also tells us approximately how significant the leak is — a rapid pressure drop vs. a slow one indicates the size of the escape point.
💨
Tracer Gas Detection
Tracer gas detection is the method of last resort for the most challenging cases — it adds cost and setup time. We use it when acoustic and thermal methods haven't produced a definitive location and the evidence clearly supports an active leak.
What We Locate
Hidden Leak Types We Find and Document
Our detection service covers the full property, not just the obvious locations.
Under Slab
Slab Leak Detection
Confirmed slab leak location is documented with a marked point on the floor and provided to you in the written detection report, with coordinates relative to fixed reference points for the repair crew.
In-Wall
In-Wall & Ceiling Leak Detection
Wall and ceiling leaks are often traced by following a visible stain to its apparent high point — but the visible damage can be several feet from the actual pipe failure due to how water travels down framing members. Thermal imaging reveals the wet zone accurately, and acoustic equipment confirms the pipe location within the wall cavity.
Water Main
Underground Supply Line Detection
Supply lines between the meter and the structure run underground and are vulnerable to corrosion, ground movement, and tree root damage. A main supply line leak shows as unusually high meter usage with all interior fixtures off, sometimes with wet ground or sinkholes along the line path. Acoustic detection locates the failure in the buried line precisely enough to minimize excavation footprint.
Pool & Irrigation
Pool Line & Irrigation Leak Detection
Pool plumbing — suction and return lines buried between the equipment pad and the pool shell — can develop leaks at fittings or in the pipe body that appear as unexplained water loss. We pressure-test the pool plumbing circuit, isolate the return and suction lines separately, and use acoustic detection to find which line and where.
Commercial
Commercial Property Leak Detection
Multi-story buildings, commercial kitchens, retail spaces, and industrial properties have complex pipe networks where a supply or drain leak can go undetected through multiple floors before surfacing. We approach commercial detection systematically — zone by zone pressure isolation, thermal scan of suspect surfaces, and acoustic confirmation.
Documentation
Leak Detection Report for Insurance
We format detection reports specifically for insurance submission and can provide documentation on our detection equipment and methodology to claims adjusters on request.
Here's exactly how a Masters Plumbing Service leak detection call plays out.
1
Initial Water Loss Confirmation
This step confirms we're looking for a real leak rather than meter error or a normal appliance cycling.
2
Zone Isolation & Pressure Decay
We isolate the supply system into zones — hot side, cold side, and if possible, individual branches — and pressure-test each zone to determine which branch is losing water. This narrows the area of active search significantly before detection equipment is deployed.
3
Detection Equipment Deployment
Within the isolated zone, we deploy thermal imaging first — scanning walls, floors, and ceilings for moisture anomalies. Then acoustic equipment confirms the specific pipe location and narrows it to the tightest possible point. Tracer gas is added if acoustic results aren't conclusive.
4
Written Report & Repair Options
Insurance claims: the report is formatted to support a claim for water damage from a concealed leak. We can provide supplemental documentation on request.
Customer Reviews
What Customers Say About Our Detection Service
★★★★★
My water bill doubled over three months with no change in usage. Masters Plumbing Service came out, confirmed the meter was moving with everything off, isolated the cold supply to the kitchen as the failing branch, and used the acoustic device on the slab to pinpoint a location 4 feet from the outside wall under the kitchen floor. The repair crew opened a 10-inch circle in the tile, found a pinhole in a copper elbow exactly where detection said it would be. I was skeptical acoustic detection was that precise — it was.
— C. Thornton, Carr
★★★★★
Our insurance company required professional leak detection documentation before approving the claim. Masters Plumbing Service's written report with pressure test data and thermal imagery was exactly what the adjuster needed. Claim approved. The detection cost was covered as part of the claim.
— B. Osei, Carr, CO
★★★★★
Pool was losing 2 inches of water per day — more than evaporation could explain. Masters Plumbing Service pressure-tested the plumbing circuit, isolated the issue to the return line, and ran acoustic detection along the line path to find the failure at a union fitting under the decking. Repair required pulling one deck board instead of the exploratory digging another company had proposed. Excellent, focused work.
— T. Anand, Carr, CO
Common Questions
Leak Detection Questions We Answer in Carr
The most reliable self-check: shut off every fixture and appliance in the house, then watch the water meter for 15 minutes. Any movement — including the small leak indicator dial — means water is escaping the supply side somewhere. If the main meter dial moves with everything off, you have a leak. Call us to locate it.
The repair itself requires physical pipe access, which typically means a small, targeted opening. But that's a completely different proposition from opening large wall sections while searching for an unknown leak location.
For pressurized supply lines in concrete or metal pipe, acoustic detection is typically accurate to within 6–18 inches under ideal conditions — quiet environment, no interference from other water use, metal pipe conducting sound clearly. Thermal imaging is accurate to the size of the wet zone it reveals, which varies based on how long the leak has been running and how far moisture has migrated.
Yes. Our written detection report includes: technician credentials, equipment identification, pressure test methodology and results, detection method description, leak location with reference measurements, and supporting thermal imagery. This is the documentation format most insurance adjusters require to approve a concealed-leak water damage claim.
We don't rush the detection protocol. The acoustic hold time and thermal scan coverage determine accuracy — cutting them short to save time produces uncertain results that cost more to act on.
Yes — and for most residential leaks, we can repair the failure the same day detection confirms the location. Our service trucks carry the repair materials for the most common supply line failures. We quote the repair as a flat-rate job separate from the detection fee, and you decide whether to proceed with us or take the detection report to your own plumber.
Service Area
Serving Carr and the Surrounding Carr, CO Region
Masters Plumbing Service provides professional Leak Detection for residential and commercial properties throughout Carr and the surrounding Carr, CO service area. Detection appointments available most weekdays and Saturdays.
